Glorystar Tube Automation solutions help manufacturers automate tube loading and material feeding operations for tube laser cutting systems. Designed to reduce manual handling, improve machine utilization, and support scalable production growth, these systems help fabricators process more material with greater efficiency and consistency.
Whether producing structural steel components, agricultural equipment, construction products, furniture, fitness equipment, or industrial assemblies, tube automation helps streamline workflow while supporting higher production volumes and reduced labor requirements.
Glorystar Tube Automation solutions are designed to automate the loading and feeding of round, square, rectangular, and structural tube profiles into tube laser cutting systems. Available in semi-automatic, fully automatic bundle-loading, and servo-driven conveyor-loading configurations, these systems help manufacturers improve throughput, reduce operator involvement, and maximize the performance of their tube laser equipment.
Automation options are available to support a variety of tube sizes, lengths, and production requirements, allowing manufacturers to select the level of automation that best fits their operation today while supporting future growth.
Semi-Automatic Tube Loading
The Semi-Automatic Tube Loading System assists operators with material feeding while maintaining flexibility for mixed-production environments. Designed for manufacturers processing a variety of tube sizes and profiles, it reduces manual loading effort while providing a practical entry point into tube automation.
Fully Automatic Tube Loading
The Fully Automatic Tube Loading System automatically feeds bundled tube material into the tube laser, minimizing operator involvement and supporting continuous production. It is ideal for manufacturers seeking higher throughput and greater automation in high-volume production environments.
Key Features
Servo-Driven Automatic Tube Loading System:
The Servo-Driven Automatic Tube Loading System is designed for larger tube diameters, heavier materials, and demanding production environments. Using a powered conveyor-based loading system, it provides reliable automated feeding while supporting high-capacity tube processing applications.
Key Features
Increase Throughput
Reduce Labor Requirements
Improve Production Consistency
Enhance Workplace Safety
Maximize Machine Utilization
Material Type | Round/square tubes, channel steel, etc. | |
Feeding Method | Arranged feeding | |
Feeding Quantity per Time | 6 pieces | |
Feeding Length | m | 5.6 – 6.2 |
ft | 18.4 – 20.3 | |
Max Weight per Tube | kg | <120 |
lb | <265 | |
Max Load Capacity | T | 1 |
lb | 2205 | |
Rack Dimensions | mm | 5200 x 2100 x 950 |
ft | 17.1 x 6.9 x 3.1 | |
Designed For | 120 – 240 chuck machines with 6 – 12-meter tubes feeding capacity | |
Considering Other Options?
Material Type | Round, square, rectangular tubes, etc. | |
Feeding Method | Entire bundle hoisting | |
Feeding Length | m | 4 – 6 |
ft | 13.1 – 20 | |
Max Weight per Tube | kg | <200 |
lb | <441 | |
Max Load Capacity | T | 2 |
lb | 4410 | |
Rack Dimensions | mm | 7600 x 3600 x 1600 |
ft | 25 x 12 x 5.3 | |
Designed For | 240 chuck machines with 6-meter tubes feeding capacity | |
Considering Other Options?
360 – 560 Chuck Size | 690 – 860 Chuck Size | ||
Material Type | Round/square tubes, channel steel, etc. | ||
Feeding Method | Arranged feeding | ||
Tube Quantity per Cycle | 5 pieces | 4 pieces | |
Tube Length | m | 6 – 12 | 6 – 12 |
ft | 19.7 – 39.4 | 19.7 – 39.4 | |
Max Load Capacity | T | 9 | 12 |
lb | 19842 | 26455 | |
Rack Dimensions | mm | 30000 x 6300 | 32000 x 11000 |
ft | 98.4 x 20.7 | 105 x 36 | |
Designed For | Chuck machines with 6 – 12-meter tubes feeding capacity | ||
Considering Other Options?
A: Glorystar offers multiple tube loading solutions designed to support different production requirements, including:
Automation options are available for a variety of tube sizes, lengths, and machine configurations.
A: Tube automation is ideal for manufacturers seeking to increase productivity, reduce labor requirements, and improve machine utilization. Common industries and applications include:
A: Glorystar tube automation systems are designed to handle a variety of tube and profile types, including round, square, rectangular, and structural profiles. Material capabilities vary depending on the automation configuration, tube size, tube length, and machine model.
A: The ideal automation solution depends on tube size, tube length, production volume, and future growth plans. Semi-automatic systems provide flexibility for mixed-production environments, while fully automatic and servo-driven systems are designed for higher production volumes and greater levels of automation.
Bramac Machinery can help evaluate your application and recommend the most appropriate solution.
A: Tube automation reduces the time spent loading and feeding material into the machine, allowing the tube laser to spend more time processing parts. By minimizing manual handling and production interruptions, manufacturers can improve throughput, increase machine utilization, and create a more efficient production workflow.
